Emperor Single Cable Cleat 32-39mm SS316L
Product information
| Suitable for pipe diameter : | 32 - 39 mm |
|---|---|
| Closed : | Yes |
| Material : | Stainless steel |
| Material quality : | Stainless steel 316 (V4A) |
| Surface protection : | Untreated |
| Max. number of tubes : | 1 |
| Type of fastening : | Screw hole |
| With inlay : | Yes |
| Colour : | Stainless steel |
| Operating temperature : | -40 - 60 °C |
| Halogen free : | Yes |
Heavy Duty Compact Stainless Steel Cable Cleat, for cables in single formation.
- 316L stainless steel frame and fixings.
- Soft LSF polymeric liner protects cable sheath.
- Captive closure fixings for fast install.
- Short circuit and mechanically tested to IEC 61914.
- ABS and DNV type approved and also UL listed.
The Ellis Emperor™ cable cleat has been designed, developed, tested and manufactured in accordance with IEC 61914 (cable cleats for electrical installations).
This cleat is suitable for single cable formation and comes in a range of sizes. It is also available in trefoil and quad formation. The frame of the cleat is manufactured from corrosion-resistant grade 316L stainless steel, the cable is supported by a liner manufactured from a low smoke zero halogen (LSOH) material.
The closure fixings are manufactured from grade A4-70 stainless steel. The Emperor can be fixed to the supporting structure by either two M10 fixings or one M12 fixing. Non-standard cleat designs can be supplied upon request.
Emperor Ellis_INSTALLAION INSTRUCTIONS
