Cable Tray 60x500mm RVS304 Non Perforated

Product number: ECT60-500-SS304-NP
Brand: Eurostrut
Check icon
Fast delivery
Check icon
20 years of expertise and experience
Check icon
Own brand of high quality
Phone icon Need help? Call us +31 10 522 33 51
Material quality
Width
Bekijk alle varianten

Variations

Product number
ECT60-075-HDG-NP
Height
Width
Length
Material quality
Height:
60 mm
Width:
75 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-100-HDG-NP
Height:
60 mm
Width:
100 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-150-HDG-NP
Height:
60 mm
Width:
150 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-200-HDG-NP
Height:
60 mm
Width:
200 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-300-HDG-NP
Height:
60 mm
Width:
300 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-400-HDG-NP
Height:
60 mm
Width:
400 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-500-HDG-NP
Height:
60 mm
Width:
500 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-600-HDG-NP
Height:
60 mm
Width:
600 mm
Length:
3000 mm
Material quality:
Hot dip galvanized
Product number
ECT60-075-SS316-NP
Height
Width
Length
Material quality
Height:
60 mm
Width:
75 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-100-SS316-NP
Height:
60 mm
Width:
100 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-150-SS316-NP
Height:
60 mm
Width:
150 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-200-SS316-NP
Height:
60 mm
Width:
200 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-300-SS316-NP
Height:
60 mm
Width:
300 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-400-SS316-NP
Height:
60 mm
Width:
400 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-500-SS316-NP
Height:
60 mm
Width:
500 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-600-SS316-NP
Height:
60 mm
Width:
600 mm
Length:
3000 mm
Material quality:
Stainless Steel 316
Product number
ECT60-075-SS304-NP
Height
Width
Length
Material quality
Height:
60 mm
Width:
75 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-100-SS304-NP
Height:
60 mm
Width:
100 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-150-SS304-NP
Height:
60 mm
Width:
150 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-200-SS304-NP
Height:
60 mm
Width:
200 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-300-SS304-NP
Height:
60 mm
Width:
300 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-400-SS304-NP
Height:
60 mm
Width:
400 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-500-SS304-NP
Height:
60 mm
Width:
500 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-600-SS304-NP
Height:
60 mm
Width:
600 mm
Length:
3000 mm
Material quality:
Stainless Steel 304
Product number
ECT60-075-PG-NP
Height
Width
Length
Material quality
Height:
60 mm
Width:
75 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-100-PG-NP
Height:
60 mm
Width:
100 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-150-PG-NP
Height:
60 mm
Width:
150 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-200-PG-NP
Height:
60 mm
Width:
200 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-300-PG-NP
Height:
60 mm
Width:
300 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-400-PG-NP
Height:
60 mm
Width:
400 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-500-PG-NP
Height:
60 mm
Width:
500 mm
Length:
3000 mm
Material quality:
Pre galvanized
Product number
ECT60-600-PG-NP
Height:
60 mm
Width:
600 mm
Length:
3000 mm
Material quality:
Pre galvanized

Product information

Height : 60 mm
Width : 500 mm
Material thickness : 1.2 mm
Length : 3000 mm
With cover : No
Side perforation : No
Bottom perforation : No
Model : Without connector
Type of connection : Screwed
Material : Stainless steel
Material quality : Stainless steel 304 (V2A)
Colour : Stainless steel
Cable Tray 60x500mm RVS304 with sizes H=60mm, W=500mm, E (thickness)=1,2mm, L=3000mm, stainless steel 304, non perforated.

Cable tray ECT60 is a closed cable support system for routing and supporting power and data cables in heavy industrial, utility, and infrastructure installations. The non-perforated version is specifically intended for applications where increased mechanical protection of cables is required or where the ingress of dirt, dust, and dripping moisture must be limited. The cable tray is suitable for wall and ceiling mounting within robust installations.

The standard version is manufactured from hot dip galvanized carbon steel according to NEN-EN-ISO 1461, with a high coating thickness of minimum 60 µm, suitable for heavy industrial and outdoor environments. The hot dip galvanizing process is applied after fabrication and provides full protection of the surface, including cut edges. This makes the system suitable for applications with increased mechanical loads and corrosive influences, in accordance with IEC 61537 and installations compliant with NEN 1010.

The cable tray features a closed U-profile without bottom perforation, resulting in increased cable protection and a stable construction. The system is part of the Eurostrut ECT60 program and is compatible with matching couplers, bends, T-pieces, risers, and covers. Installation is possible using standard wall, ceiling, and suspension brackets from the Eurostrut range.

Technical Specifications

  • Product type: Closed cable tray, non-perforated
  • System height: 60 mm
  • System width: 75 to 600 mm
  • Standard material: Carbon steel
  • Surface finish: Hot dip galvanized according to NEN-EN-ISO 1461
  • Zinc coating thickness: minimum 60 µm
  • Design: Closed U-profile without bottom perforation
  • Standards: IEC 61537, applicable within installations compliant with NEN 1010

Typical Applications

  • Heavy industrial installations
  • Outdoor installations and harsh industrial environments
  • Cable routes with increased requirements for mechanical protection
  • Installations where contamination or moisture ingress must be limited

Available Material Variants

  • PG: Pre galvanized carbon steel according to EN 10346, suitable for dry indoor environments and light industrial applications.
  • HDG: Hot dip galvanized carbon steel according to NEN-EN-ISO 1461, with a high coating thickness of minimum 60 µm, suitable for heavy industrial and outdoor environments.
  • Stainless steel 304 (A2 / 1.4301): Stainless steel for indoor environments and lightly corrosive conditions.
  • Stainless steel 316 (A4 / 1.4404): Stainless steel with enhanced corrosion resistance for chemical, maritime, and offshore applications.

Complementary Products

For a complete installation, Eurostrut offers a wide range of accessories, such as:

  • Couplers: Straight coupling plates and expansion couplers for ECT60 systems
  • Bends and branches: Horizontal and vertical bends, T-pieces, and cross pieces
  • Mounting brackets: Wall, ceiling, and suspension brackets compatible with ECT60
  • Covers and fixings: Covers and corresponding fixing clips

These components ensure a safe, compatible, and maintenance-friendly installation.

Other lengths and widths available on request.
