Cable Protection Slotted 60mm HDG
Product number:
SRL-60-FT
Brand:
Eurostrut
Fast delivery
20 years of expertise and experience
Own brand of high quality
Want to view our prices?
Our pricing is exclusively available to registered customers.
Variations
Product number
Outer diameter
Inner diameter
Material quality
Outer diameter:
60.3 mm
Inner diameter:
56 mm
Material quality:
Hot dip galvanized
Product number
Outer diameter
Inner diameter
Material quality
Outer diameter:
60.3 mm
Inner diameter:
56 mm
Material quality:
Stainless Steel 316
Product number
Outer diameter
Inner diameter
Material quality
Outer diameter:
60.3 mm
Inner diameter:
56 mm
Material quality:
Stainless Steel 304
Product information
| Material : | Steel |
|---|---|
| Material quality : | Steel (strip steel rolled) |
| Surface protection : | Hot-dip galvanised |
| Model : | Rigid |
| Connection 1 : | Tube end |
| Connection 2 : | Tube end |
| Colour : | Zinc |
| Inner diameter : | 56 mm |
| Outer diameter : | 60.3 mm |
The Eurostrut SRL-60-FT is a robust cable protection tube made from cold-rolled structural steel S235JRG. It is hot-dip galvanized according to NEN-EN-ISO 1461 with a minimum zinc layer of 45 µm, offering excellent corrosion resistance. The tube has an outer diameter of 60.3 mm, an inner diameter of 56 mm, and a wall thickness of 2.0 mm. Laser-cut entry slots measuring 100 x 28 mm allow for easy cable access.
Technical specifications:
- Material: Cold-rolled structural steel S235JRG
- Surface treatment: Hot-dip galvanized according to NEN-EN-ISO 1461 (min. 45 µm)
- Length: 6 meters
- Outer diameter: 60.3 mm
- Inner diameter: 56 mm
- Wall thickness: 2.0 mm
- Laser-cut slots: 100 x 28 mm
Applications:
- Industrial installations
- Infrastructure projects
- Machinery construction
- General cable routing and protection
Accessories and mounting options:
- Tube clamps
- Cover brackets
- Mounting plates
- Connectors
- Bends (45° and 90°)
