Crossover Cable Ladder ECL60 600mm HDG
Product number:
ECO60-600-300-HDG
Brand:
Eurostrut
Fast delivery
20 years of expertise and experience
Own brand of high quality
Want to view our prices?
Our pricing is exclusively available to registered customers.
Variations
Product number
For ladder height
Radius
For ladder width
For ladder height:
60 mm
Radius:
300 mm
For ladder width:
100 mm
Product number
For ladder height
Radius
For ladder width
For ladder height:
60 mm
Radius:
300 mm
For ladder width:
100 mm
Product number
For ladder height
Radius
For ladder width
For ladder height:
60 mm
Radius:
300 mm
For ladder width:
100 mm
Product information
| Type of side joist : | Flat profile |
|---|---|
| Type of rung : | Perforated profile |
| Suitable for cable ladder height : | 60 mm |
| Suitable for cable ladder width : | 600 mm |
| Inner radius : | 300 mm |
| Material : | Steel |
| Material quality : | Other |
| Surface protection : | Hot-dip galvanised |
| Colour : | Zinc |
voor kabelladder ECL60, H=60mm, W=600mm, T=3,0mm, R=300, Hot Dip Galvanized Carbon Steel, layer 60 to 70µm, including 32x ESL-SB-H Eurostrut fixing set (square neck bolt M10x20, nut and washer). Heavy Duty.
voor kabelladder ECL60, H=60mm, B=600mm, D=3,0mm, R=300, Koolstofstaal Thermisch Verzinkt, beschermlaag 60 tot 70µm, inclusief 32x ESL-SB-H Eurostrut bevestigingsset (slotbout M10x20, moer en sluitring). Heavy Duty.
