Mounting Bracket 175x260mm Cable Protection Tube 30mm HDG
Product number:
SMII-30-FT
Brand:
Eurostrut
Fast delivery
20 years of expertise and experience
Own brand of high quality
Variations
Product number
Height
Width
Outer diameter
Material quality
Height:
260 mm
Width:
175 mm
Outer diameter:
30 mm
Material quality:
Hot dip galvanized
Product number
Height
Width
Outer diameter
Material quality
Height:
260 mm
Width:
175 mm
Outer diameter:
30 mm
Material quality:
Stainless Steel 316
Product number
Height
Width
Outer diameter
Material quality
Height:
260 mm
Width:
175 mm
Outer diameter:
30 mm
Material quality:
Stainless Steel 304
Product information
| Material : | Metal |
|---|---|
| Surface protection : | Hot-dip galvanised |
| Type of fastening : | Screw hole |
| Number of cables/conduits : | 1 |
| Outer diameter : | 30 mm |
| Width : | 175 mm |
| Height : | 260 mm |
The SMII-30-FT is a 175 x 260 mm mounting plate designed for securely fixing cable protection tubes with a diameter of 30 mm to various surfaces. It ensures stable support in both industrial and technical environments.
Made from structural steel S235JRG and hot-dip galvanized in accordance with NEN-EN-ISO 1461, featuring a minimum zinc layer of 45 µm, this plate offers excellent corrosion resistance for indoor and outdoor use.
- Material: Structural steel S235JRG
- Finish: Hot-dip galvanized to NEN-EN-ISO 1461 (min. 45 µm)
- Dimensions: 175 x 260 mm
- For tube diameter: 30 mm
- Thickness: 3 mm
- Includes: 2x hose clamps SS9-30-ER2
- Compatible with: SR-30-FT and SRL-30-FT cable protection tubes
- Mounting: Secured to flat surfaces using screw holes
Applications:
- Fixation of cable protection tubes to floors and walls
- Industrial and infrastructure installations
- Support for tube systems in diverse environments
