Divider Marine Ladder HDG
Product number:
ESL-DIV-H
Brand:
Eurostrut
Fast delivery
20 years of expertise and experience
Own brand of high quality
Want to view our prices?
Our pricing is exclusively available to registered customers.
Variations
Product number
Length
Height
Material quality
Length:
3000 mm
Height:
15 mm
Material quality:
Hot dip galvanized
Product number
Length
Height
Material quality
Length:
3000 mm
Height:
15 mm
Material quality:
Stainless Steel 316
Product number
Length
Height
Material quality
Length:
3000 mm
Height:
15 mm
Material quality:
Stainless Steel 304
Product information
| Partition height : | 15 mm |
|---|---|
| Length : | 3000 mm |
| Model : | L-profile |
| Mounting perforation : | Yes |
| Type of fastening : | Screwable |
| Suitable for cable ladder : | Yes |
| Material : | Steel |
| Material quality : | Rustproof and acidproof steel |
| Surface protection : | Hot-dip galvanised |
| Colour : | Zinc |
The ESL‑DIV‑H is a divider plate for marine ladders – designed to separate cable bundles within the same ladder run.
Manufactured from cold-formed steel S235JRG and hot-dip galvanized in accordance with NEN‑EN‑ISO 1461. A minimum zinc layer thickness of 70 µm ensures excellent corrosion resistance in both indoor and outdoor environments.
Suitable for ladder systems with a height of 30 mm. Supplied with 3x M8x15 fixing sets.
- Material: Cold-formed steel S235JRG
- Finish: Hot-dip galvanized according to NEN‑EN‑ISO 1461 (min. 70 µm)
- Suitable for ladder height: 30 mm
- Length: 3000 mm
- Height: 15 mm
- Mounting: Includes 3x M8x15 fixing sets
